Industrial Valves and Actuators

As a service provider to a diverse number of industries Hitemp Pneumatics is able to supply a vast range of valves and controls.

Valve types available are:
Knifegate, Butterfly, Gate, Globe, Ball, Rotary, Pressure relief, and Check valves

Actuators vary from:
Electric Driven, Failsafe, Gearbox, Pneumatic and Manual Operation.

Knifegate

Knifegate

  • Available in 50 mm [2”] – 900 mm [36”]
  • Pressure Rated to 10 bar [150 PSI]
  • Wafer, Lugged or Flange Styles
  • Metal and Resilient Seats
  • Available with Hand Wheel, Chain, Gear,
  • Electric Pneumatic or Hydraulic Actuation
  • Bi Directional Shut Off
Butterfly

Butterfly

  • Sizes range from 50 mm – 900 mm
  • Pressure rated up to 16 bar
  • Wafer, Lugged or Flange Style
  • Bodies: Cast Iron, Aluminium and Stainless Steel
  • Seats: Metal and Resilient Seats
  • Available with Handles, Gear Operators, Pneumatic or Electric Actuators
  • Also available with: Solenoid Valves, Limit Switches and Positioners.
Gate Valves

Gate Valves

  • Sizes: Screwed: 15 – 50 mm and Flanged: 50 mm – 300 mm
  • Pressure CWP 1400 KPa ANSI 150RF, ANSI 300RF and ANSI 600RF
  • Flanged Type Table E and ANSI
  • Bodies: Cast Iron, Carbon Steel and Stainless Steel
  • Seat Rings: Cast Bronze, A105/Stellite and PTFE c/w 33% Chrome
  • Hand Wheel operation, rising and non rising stem
Globe Valves

Globe Valves

  • Sizes: Screwed: 15 mm – 50 mm and Flanged: 50 mm – 300 mm
  • Pressure CWP1400KPa, ANSI 150RF – ANSI 600RF
  • Flanged Table E and ANSI
  • Bodies: Cast Iron, Carbon Steel, 316 Stainless Steel
  • Seats: Glands PTFE, CF8M, Stellite and Graphite
  • Hand Wheel operation, rising and non rising stem
Ball Valves

Ball Valves

  • Full range of ball valves from:
  • Mini: Bronze and stainless steel size ? - ½” bspf and bspm/f.
  • Standard and Lockable: In sizes 8mm [¼” bsp] – 100mm [4” bsp] in nickel coated bronze and stainless steel.
  • Flanged: Up to 300mm [12”] in cast carbon steel and stainless steel
  • 3 Way ‘L’ Port and ‘T’ Port: [8mm] ¼” bsp – [50mm] 2” bsp.

Most valves from ½” up are available with levers, lockable lever, pneumatic and electric actuators.Various seat & gland packing’s are also available.

Pressure Relief Valves

Pressure Relief Valves

  • Safety relief valves in our range are designed for all applications with sizes from ?” bsp – 4” npt with flanged or screwed inlet on larger sizes.
  • Materials: Carbon steel, bronze and stainless steel.
  • Pressure Range: From 35KPa – 2400KPa
  • Operating Temperature Range: -28º C - 230º C
  • For Use: with liquids water, oil, steam, air and gas.
Check Valves

Check Valves

Styles: Swing Disc, Dual Plate and Piston in sizes from 8mm (1/4”) to 300mm (12”).

Available materials such as brass, nickel plated brass, carbon steel, cast iron and 316 stainless steel.

Rotary Valves

Australian built and imported
